PASSIVE CLT HOUSES
ARTEM REGART
®
- House in 1 monthASSEMBLYDesign, production, assembly and launch
- Eco friendlyPRODUCTIONEnvironmentally friendly passive houses
- 48 monthsPAYBACKLow heating and cooling costs
- Passive housesSUPPORTMaintenance, service, insurance, consultations
PASSIVE HOUSE
ARTEM REGART
ARTEM REGART
Passive house must have a closed loop of PIR insulation; do not have cold bridges; have panoramic energy-saving glazing; be sealed; have a supply and exhaust system of forced ventilation with heat and moisture recuperator. Passive house ARTEM REGART saves 95% of heating and air conditioning costs. It pays off in just 4 years. The microclimate that a passive house creates cannot be obtained in any other house
HOUSES FROM CLT PANELS
Any architectural solutions
Availability of ready-made CLT panels in stock
Building a house in a few days
WALLS AND FLOORS
Monolithic 5-layer wooden panels REGART CLT
Absolute absence of shrinkage and readiness for fine finishing
Large unsupported spans in the kitchen-living room 8.5 and 9 m
Closed loop of enclosing structures without blowing
Lack of vapor permeability of all layers of walls and ceilings
Dry room walls sanded and ready to paint
Fine finishing of the facade with a choice of materials
ROOF
Ceilings with a bearing capacity of 550 kg/m²
No need to shovel snow in winter
Covered with PVC membrane
Slope and counterslope 1.7 and 3.4%
WINDOWS AND DOORS
Panoramic double-glazed windows 58 mm thick
Tempered glass with I, K sputtering 10 and 8 mm thick
Double-glazed windows do not let cold or heat from the street into the house
The area of the main solid double-glazed windows is 7 m² each
General glazing of the house-apartment 30% of the facade area
WARMING
PIR insulation 140 mm on the walls
PIR insulation 160-330 mm on the roof
Energy efficiency class A+++
PASSIVE HOUSE
Ideal controlled microclimate
Complete absence of condensation on the windows
Temperature difference of 2 °C throughout the house
Keeps warm for several days without heating
Savings on heating 95%, payback in 4 years
FACADE FINISHES
Fiber cement panels in wood or brick look
Wooden planken in various colors
Terrace on gravel around the house
Terrace on a pebble roof
Summer doors to the terrace from any room
Pergola along any side of the facade of the house
Rafshtorov with installation on panoramic windows
FINISHING
Any finishing options from the best designers
Unlimited choice of materials and technologies
Any architectural solutions
Availability of ready-made CLT panels in stock
Building a house in a few days
WALLS AND FLOORS
Monolithic 5-layer wooden panels REGART CLT
Absolute absence of shrinkage and readiness for fine finishing
Large unsupported spans in the kitchen-living room 8.5 and 9 m
Closed loop of enclosing structures without blowing
Lack of vapor permeability of all layers of walls and ceilings
Dry room walls sanded and ready to paint
Fine finishing of the facade with a choice of materials
ROOF
Ceilings with a bearing capacity of 550 kg/m²
No need to shovel snow in winter
Covered with PVC membrane
Slope and counterslope 1.7 and 3.4%
WINDOWS AND DOORS
Panoramic double-glazed windows 58 mm thick
Tempered glass with I, K sputtering 10 and 8 mm thick
Double-glazed windows do not let cold or heat from the street into the house
The area of the main solid double-glazed windows is 7 m² each
General glazing of the house-apartment 30% of the facade area
WARMING
PIR insulation 140 mm on the walls
PIR insulation 160-330 mm on the roof
Energy efficiency class A+++
PASSIVE HOUSE
Ideal controlled microclimate
Complete absence of condensation on the windows
Temperature difference of 2 °C throughout the house
Keeps warm for several days without heating
Savings on heating 95%, payback in 4 years
FACADE FINISHES
Fiber cement panels in wood or brick look
Wooden planken in various colors
Terrace on gravel around the house
Terrace on a pebble roof
Summer doors to the terrace from any room
Pergola along any side of the facade of the house
Rafshtorov with installation on panoramic windows
FINISHING
Any finishing options from the best designers
Unlimited choice of materials and technologies
CLT PANELS
CLT - cross laminated timber. This is a heavy-duty structural material with a service life of more than 120 years. CLT panels do not shrink and have excellent soundproofing properties. CLT is the only wooden material from which it is allowed to build multi-storey buildings with a height of 28 m.
With Mini CLT Plants ARTEM REGART you will produce CLT panels for any of architectural projects
With Mini CLT Plants ARTEM REGART you will produce CLT panels for any of architectural projects
FIRE RESISTANCE
High fire resistance building I
Fire resistance s2, d0
Constructive fire hazard class K1
Fire resistance limit of raw floor slab REI 60
Charring rate of raw panel 0.65 mm/min
Minimal damage in the event of a fire
GLUING TYPE
Narrow side bonding
Face side bonding
PROTECTION AGAINST OVERWATERING
Vapor permeability coefficient of CLT panel 0,05 mg/(m•h•Pa)
In the security structure, hypothermia is impossible
NOISE PROTECTION
Airborne sound insulation performance index of untreated panel
Rw (C;Ctr) = 48 (-2; -5) dB
Sound insulation meets the requirements for residential buildings
ENVIRONMENTAL FRIENDLY
Formaldehyde emission from raw panel 0.005 mg/m³
PUR adhesive without odor and solvents
Eco-friendly according to the French A+ standard
Softwood without chemical treatment
SEISMIC RESISTANCE
Seismic resistance of growth according to the MMSK scale 7-8 points almost without damage
The building can withstand an earthquake up to 9 points
High fire resistance building I
Fire resistance s2, d0
Constructive fire hazard class K1
Fire resistance limit of raw floor slab REI 60
Charring rate of raw panel 0.65 mm/min
Minimal damage in the event of a fire
GLUING TYPE
Narrow side bonding
Face side bonding
PROTECTION AGAINST OVERWATERING
Vapor permeability coefficient of CLT panel 0,05 mg/(m•h•Pa)
In the security structure, hypothermia is impossible
NOISE PROTECTION
Airborne sound insulation performance index of untreated panel
Rw (C;Ctr) = 48 (-2; -5) dB
Sound insulation meets the requirements for residential buildings
ENVIRONMENTAL FRIENDLY
Formaldehyde emission from raw panel 0.005 mg/m³
PUR adhesive without odor and solvents
Eco-friendly according to the French A+ standard
Softwood without chemical treatment
SEISMIC RESISTANCE
Seismic resistance of growth according to the MMSK scale 7-8 points almost without damage
The building can withstand an earthquake up to 9 points
COMPANY
ARTEM REGART was founded in 2002
We are a comprehensive engineering company: design office, Mini CLT plants production, own experimental Mini CLT plant, serial passive houses production, technical supervision, teams of installation engineers
Founder & owner ARTEM REGART >>
ARTEM REGART was founded in 2002
We are a comprehensive engineering company: design office, Mini CLT plants production, own experimental Mini CLT plant, serial passive houses production, technical supervision, teams of installation engineers
Founder & owner ARTEM REGART >>
ASSEMBLING A CLT HOUSE
Houses from CLT are assembled on the land plot by a crane in 3 - 4 days. A team of 3 - 4 workers is needed with minimal experience with hand tools and no experience in assembling similar houses.
It's just like 1,2,3
The price of a finished house with all communications and exterior finishes starts from 600 euros / m2 without taxes
It's just like 1,2,3
The price of a finished house with all communications and exterior finishes starts from 600 euros / m2 without taxes
1
passive house DESIGN
2
clt panels Production
3
passive house assembly
4
passive house finishing
